Low Profile Equipment

Build your trailer

Select your configuration below. Specs update automatically.

Axle Configuration
Tandem Axle
Deck Style
Straight Deck Beavertail
LBAT7-Slide-in-ramps-2
LBAT7-Slide-in-ramps-1
LBAT7-Slide-in-ramps-3
LBAT7-Slide-in-ramps-4
LBAT7-Slide-in-ramps-5
LBAT7-Slide-in-ramps-6
LBAT7-Slide-in-ramps-2
LBAT7-Slide-in-ramps-1
LBAT7-Slide-in-ramps-3
LBAT7-Slide-in-ramps-4
LBAT7-Slide-in-ramps-5
LBAT7-Slide-in-ramps-6

Live Specifications

Download PDF
Axle (2) 7,000 lb Lippert Spring
Suspension Multi-Leaf Spring w/Equalizer
Wheels 235/80R16 E Steel
Brakes Electric Self Adjusting
Jack 5,000 lb Top Wind Bolted
Coupler 21,000 lb Demco Adjustable
Frame 6 X 2 HSS
Ramp Slide In or Flip Up, 4,500 lb
Crossmember 3” I-Beam 80 KSI
Tongue 6 X 2 HSS
Deck HD Fir Plank
Electric Plug 7 Wire RV
Width Between Fenders 81”
Rating Set Standard | Standard | Standard | Standard | Standard | Standard
Length (ft) 14 | 16 | 18 | 20 | 22 | 24
Net Weight (lb) 2400 | 2550 | 2700 | 2850 | 3000 | 3150
GVWR (lb) 15400 | 15400 | 15400 | 15400 | 15400 | 15400
Payload Capacity (lb) 13000 | 12850 | 12700 | 12550 | 12400 | 12250
Dimension A 59” | 78” | 86” | 95” | 112” | 120”
Dimension B 109” | 114” | 130” | 145” | 152” | 168”
Dimension C 168” | 192” | 216” | 240” | 264” | 288”
Dimension D 24 1/2” | 24 1/2” | 24 1/2” | 24 1/2” | 24 1/2” | 24 1/2”
Dimension E 224” | 248” | 272” | 296” | 320” | 344”
3-Year Warranty Structural integrity guaranteed.
Financing Available View partnerships & rates
