Live Specifications

Download PDF
Main Beams One-Piece Seamless Web 3/16”GR90 KSI HTS, Robotically Welded Flange GR130 KSI 5” x 3/8” & 1/2” Under the Neck HTS, 2.5” Camber
Main Deck Frame 6 3/16” Formed Side Rails, 4” Superlite IBeam Crossmembers on 12” Centers on Main Deck, 16” on Top Deck, 2-1/2” x 3/8” Continuous Rub Rail, Stake Pockets @ 24” Centers, Tube Style Knee Braces, Formed Front Bolster with 4 Integrated Stake Pockets and Bolted Aluminum Inspection Plate, Formed Rear Bolster with 5 Integrated Stake Pockets
Coupler Assembly 3/8” Plate Reinforced with Support Channels and Inner Web Repads, SAF Holland King Pin with Depth Set at 18”, Various Pin Depth and Plate Thickness Options Available
Cargo Securement Stake Pockets @ 24” Centers, 3 Bar Winches w/Opposite J-Hooks, Pipe Spools Between Stake Pockets, HD Tarp Hooks. Custom Winch, Pipe Spool and Stake Pocket Layouts Available
Decking 8” x 1-5/16 BC Douglas FIR Shiplap, Exterior Wood Stained for Longevity
Suspension Hendrickson AAL23K INTRAAX Air Ride 8” Ride Height. Options Available
Axles Hendrickson AAL23K INTRAAX, Lift Axle and Tire Inflation Options Available
Wheelends/Brakes Standard 10 Stud Piloted Ductile Iron Hub, Extended Life HXL5, Haldex Auto Slack Adjusters, HXS TSE 30/30 Spring Brake Pots. Cast Drum, Federal Mogul Seals. Disc Brake, Hubmeter and Lightweight Hub and Drum Options Available.
ABS Bendix TABS-6 ABS (2 Sensors/1 Modulator), Transport Canada Compliant
Coating All Components Steel Shot Blasted, PPG Zinc Rich Epoxy Primer Inside and Out, Top Coat PPG Urethane, All Painted Parts Baked in Heat Ovens, Standard Black. Various Colors Available.
Wiring/Lighting HD Sealed Grote Wiring Harness with LED lighting, Wide Load Pull Out and Rear Rear Strobe Lights Options Available.
Air System Standard Steel Air tanks, Inline Air Filter System, Manual Air Bag Dump Valve
Landing Gear 62,500 lb Dual Speed SAF Holland Mark V with Sand Shoe
Tires Cooper Roadmaster. Options Available
Rims Steel and Aluminum, Various Finish Options Available
Toolbox/Storage Aluminum Box with Barn Doors 18”H x 23”D x 56.5”L with Cam Style Latch and Grote LED Interior Light. Various Dunnage Box, Rack and Basket Options Available. Optional Chain Hanger
Mudflaps 30” Poly Anti-Spray Renn Logo’d Mudflaps. Options Available
Tow Point Plate with Hole, Mounted at Rear
Dock Bumper 2 – Mounted at Rear
Reflective Conspicuity 2” Red and White
Document Holder Tube Style
Control Box Sealed Aluminum Box with Sight Window, Liquid Load Gauge and Manual Air Bag Dump Valve
Bumper Certified Rear Impact Guard, Meets CMVSS
Data Meets or Exceeds all Canadian Motor Vehicle Safety Standards
GVWR 84,877 lb
Distributed 70,000 lb
20' Concentrated 60,000 lb
10' Concentrated 51,000 lb
4' Concentrated 45,000 lb
Tare 14,200 lb
Deck Length 53'
Outside Width 102"
Top Deck 11'
Bottom Deck 42'
Rear Loaded Deck Height 41"
King Pin Plate Height 49.5"
Rating Set Standard
Length (ft) 53
Net Weight (lb) 14200
GVWR (lb) 84877
3-Year Warranty Structural integrity guaranteed.
